Description
The Sophos XG330 appliance is designed to provide the optimal balance between performance and protection – for diverse IT environments.
These entry-level desktop firewalls are the ideal choice for budget-conscious small businesses, retail and small or home offices.
They are available with and without integrated wireless LAN, so you can have an all-in-one network security and hotspot solution without the need for additional hardware.
The Intel dual-core technology makes them highly efficient and as they’re fanless, they won’t add unwanted noise to your office space.
Technical Specifications
| XG 210 | XG 230 | XG 310 | XG 330 | |
| Firewall throughput: | 16 Gbps | 20 Gbps | 28 Gbps | 33 Gbps |
| Firewall IMIX: | 5.5 Gbps | 6.8 Gbps | 9.5 Gbps | 12.5 Gbps |
| VPN throughput: | 1.45 Gbps | 1.7 Gbps | 2.75 Gbps | 3.2 Gbps |
| IPS throughput: | 2.7 Gbps | 4.2 Gbps | 5.5 Gbps | 8.5 Gbps |
| NGFW (IPS + App Ctrl) max.: | 2.2 Gbps | 3 Gbps | 4 Gbps | 5.5 Gbps |
| Antivirus throughput (proxy): | 2.3 Gbps | 2.8 Gbps | 3.3 Gbps | 6 Gbps |
| Concurrent connections: | 8200000 | 8200000 | 17500000 | 17500000 |
| New connections/sec: | 135000 | 140000 | 200000 | 200000 |
| Maximum licensed users: | unrestricted | unrestricted | unrestricted | unrestricted |
| CPU (Core/Threads): | Celeron G3900 (2/2) | Pentium G4400 (2/2) | Core I3 6100 (2/4) | Core I5 6500 (4/4) |
| Arbeitsspeicher: | 8GB DDR4 | 8GB DDR4 | 12GB DDR4 | 12GB DDR4 |
| Storage (local quarantine/logs): | 120 GB SSD | 120 GB SSD | 180 GB SSD | 180 GB SSD |
| Ethernet interfaces (fixed): | 6 GbE copper (incl. 2 bypass pairs) 2 GbE SFP* | 6 GbE copper (incl. 2 bypass pairs) 2 GbE SFP* | 8 GbE copper (incl. 2 bypass pairs) 2 GbE SFP*, 2 10 GbE SFP+* | 8 GbE copper (incl. 2 bypass pairs) 2 GbE SFP*, 2 10 GbE SFP+* |
| Ethernet interfaces (removable): | – | – | – | – |
| I/O ports: | 2 x USB 3.0 (front), 1 x Micro USB (front) 1 x USB 3.0 (rear), 1 x COM (RJ45) (front) 1 x HDMI (rear) | 2 x USB 3.0 (front), 1 x Micro USB (front) 1 x USB 3.0 (rear), 1 x COM (RJ45) (front) 1 x HDMI (rear) | 2 x USB 3.0 (front), 1 x Micro USB (front) 1 x USB 3.0 (rear), 1 x COM (RJ45) (front) 1 x HDMI (rear) | 2 x USB 3.0 (front), 1 x Micro USB (front) 1 x USB 3.0 (rear), 1 x COM (RJ45) (front) 1 x HDMI (rear) |
| Power supply: | Internal auto-ranging 100-240VAC, 50-60 Hz Redundant PSU optional (external) | Internal auto-ranging 100-240VAC, 50-60 Hz Redundant PSU optional (external) | Internal auto-ranging 100-240VAC, 50-60 Hz Redundant PSU optional (external) | Internal auto-ranging 100-240VAC, 50-60 Hz Redundant PSU optional (external) |
| Mounting: | 1U rack mount (2 rackmount ears included) | 1U rack mount (2 rackmount ears included) | 1U rack mount (2 rackmount ears included) | 1U rack mount (2 rackmount ears included) |
| Dimensions Width x Depth x Height: | 438 x 344.4 x 44mm 17.24 x 13.56 x 1.75 inches | 438 x 344.4 x 44mm 17.24 x 13.56 x 1.75 inches | 438 x 405.5 x 44mm 17.24 x 15.96 x 1.75 inches | 438 x 405.5 x 44mm 17.24 x 15.96 x 1.75 inches |
| Weight: | 5.2 kg / 11.46lb (unpacked) 7.7 kg / 16.98 lbs (packed) | 5.2 kg / 11.46lb (unpacked) 7.7 kg / 16.98 lbs (packed) | 5.8 kg / 12.78 lbs (unpacked) 8.8 kg / 19.4 lbs (packed) | 5.8 kg / 12.78 lbs (unpacked) 8.8 kg / 19.4 lbs (packed) |
| Power consumption: | 19W, 65 BTU/hr (idle) 35W, 119 BTU/hr (full load) | 21W, 72 BTU/hr (idle) 41W, 141 BTU/hr (full load) | 32W, 109 BTU/hr (idle) 49W, 167 BTU/hr (full load) | 36W, 122 BTU/hr (idle) 54W, 184 BTU/hr (full load) |
| Operating temperature: | 0-40°C (operating) -20 to +80°C (storage) | 0-40°C (operating) -20 to +80°C (storage) | 0-40°C (operating) -20 to +80°C (storage) | 0-40°C (operating) -20 to +80°C (storage) |
| Humidity: | 10%-90%, non-condensing | 10%-90%, non-condensing | 10%-90%, non-condensing | 10%-90%, non-condensing |
| Noise-Level (idle/load in dBA): | 37/57 | 37/57 | 25/58 | 25/58 |
| Certifications: | CB, UL, CE, FCC Class A, ISED, VCCI, RCM, CCC, KC, BIS | CB, UL, CE, FCC Class A, ISED, VCCI, RCM, CCC, KC, BIS | CB, UL, CE, FCC Class A, ISED, VCCI, RCM, CCC, KC, BIS | CB, UL, CE, FCC Class A, ISED, VCCI, RCM, CCC, KC, BIS |
With the Sophos XG 330 you bring your network security to an all-time high level.
The replacement to the SG series comes with the all-new Sophos Firewall OS (SFOS). The operating system brings a whole new level of firewall management to the market. It fits perfectly into any network and can also work with other security systems around it, giving you unprecedented levels of simplicity, insight and advanced threat protection. Intel multi-core technology gives Sophos XG 330 the best performance and efficiency. Its small form factor allows it to work quietly in the background.
An SSD is used for logs, on-box reporting and spam quarantine. Thanks to its high performance, the XG 330 can react appropriately even in extreme situations. Based on the latest Intel technology with 8 GbE copper ports, 2 GbE SFP fiber ports and a flexi port slot, it offers high flexibility and throughput at an excellent price-performance ratio.
